Secuplus small parcel X ray inspection system for hospital, hotel

Product Description

Secuplus small parcel x ray inspection system for hospital, hotel
Handbag X Ray Luggage Scanner Screening Machine for army base, factory
Handbag X Ray Screening Machine for Small Baggage

SPX-5030A adopt Multi- energy x-ray generator, real color scanning image can distinguish the organic and inorganic objects in different color, assist to detect the suspicious explosive and narcotics, automatic alarming for high density objects.It's widely used in the hotels shopping malls, subways, schools, factories and other infrastructures.

Technic Specifications:

Tunnel Size504(W)*320(H)mm
Conveyor Speed0.22m/s
Conveyor Max Load100kg
Dose per Inspection<2.9μ Gy/h
Resolution<0.101mm Metal Wire
Spatial resolution Level: Dia1.0mm, Vertical: Dia1.3mm
Penetrate resolutionDia 0.511mm
Penetration10mm steel
Film SafetyGuarantee ISO1600 Film
X-ray Leakage<0.5 μ Gy/h (at a distance of 5cm From external housing)
Image System :
Technical PrincipleDual-energy X-ray Imaging; L Shaped Array
X-ray SensorL-Shaped Photodiode Array (multi-energetic)
MonitorHigh Resolution Color, LCD Accord, 17inch
Image DisplayHigh resolution of 1024 * 1280 pixel; Image Grey Level: 65536
Image Enhancement1-64times enlargement continuity, Color/BW, negative, high/low
penetration, organic /inorganic Stripping, general enhancement, and pseudo color, etc.
Image Recall:All preceding images recallable, retrieval.
Explosives & Narcotics DetectionExplosives & narcotics alarm and highlight according to atomic number signature
High Density Region AlarmImpenetrable region alarm and highlight, for possible concealing of
threats and contrabands
Image ArchiveUp to 100,000 images stored automatically, enable transferring to USB disk, and
converting to JPG, BMP and other general formats
Miscellaneous FunctionsTime/date display, counters, user management, system-on/X-ray-on
timers, power on self test, built-in diagnostic facilities, dual-direction scanning, system log, system standby and stimulant training,etc
Network ApplicationsMultiple remote applications available based on Ethernet LAN and
windows platform, such as image centralized storage and identify, recheck workstation, and network TIP, etc ( Optional) .
Images process24bit real time processing ,4colors analysis, Images displayed marked date and ID NO ,Count the number of bags ,Memory gray level:65536
Operating Environment:
Operation temperature/Humidity0ºC-40ºC/10%-95%(non-condensing)
Storage Temperature/Humidity-20ºCto 60ºC/ 5%-95%(non-condensing)
Operation Power220VAC(±10%)50±3Hz (Optional: 100VAC,110VAC,120VAC,200VAC)
Power Consumption1.0KW (max), 0.7KW(working)
Noise<58db
Scanner Dimensions (L×W×H) 1660mm x746mm x1165 mm
Gross Weight280kgs
Packing Volume1.5 CBM
X-ray Generator:
Anode Voltage80kv
Anode Power0.6 MA
Generate angle80 degree upward
BrandChinese Brand
Generate direct from bottom to top
Cooling / Duty CycleOil Cooling /100


Product highlights:

* Multilingual operation
* Automatic built in test and self diagnosis
* Secure access Key
* Continuous working 10000 hours above
* Threat alert and material classification
* International standard configuration:
   Japan Hammatsu detection and UK Sens-tech board
* Network‐Ready
* Energy saving design
* One key turn off
* Drugs and explosives inspection
* Indication of the date and time

RFQ:

Are you manufacturer?
Yes, we are professsional manufacturer of security threats detection system in south of China.
Stable quality and foremost service always be the key that we focus on.

How many days we can get the machine after payment?
Normally, with stock only need 3-5 days for leading time.
Without stock, need 10-15 days to manage the production.
Delivery by sea, air for your choices.

How about the warranty and services?
Provide one year warranty and lifetime technic support.
Accept to send our engineer to your country for training in additional cost.
Free training one-on-one in our factory for free.
